Product Description
1. Low fuel consumption, low noise, low pollution, high efficiency and environmental protection.
2. Our products has the strict test system, the voltage and frequency is stability
3. FOB price, high quality and good service.
4. Diverse styles and humanized choice, and can be widely used in the family supermarkets hotels, pleases such as the temporary outage.
| Rated frequency(Hz) | 50 60 |
| Rated voltage(V) | 230 230 |
| Rated current(A) | 41.3 45.7 |
| Rated output power(kW) | 9.5 10.5 |
| Max output power(kW) | 10.5 11.5 |
| DC output | 12V 8.3A |
| Power factor(cos) | 1.0 |
| Phase number | Single phase |
| Rated rotation speed(rpm) | 3000 3600 |
| Structure type | Silent type |
| Noise level dB(A)7m | 70~75 |
| Overall dimension(L*W*H)(mm) | 1180*610*830 |
| Dry weight(kg) | 272 |
| Engine model | KM290F/E |
| Fuel tank volume(L) | 25 |
| Total displacement[L(cu. in)] | 0.954(58.22) |
| Fuel consumption rate[g(ml)/kW. h] | ≤ 270(321)/3000 290(345)/3600 |
| Starting mode | 12V electric statrt |
| Bore*stroke[mm(in)] | 90*75(3.54*2.95) |
| Type | Double cylinder, air-cooled, 4-stroke, direct injection, diesel engine |
| Fuel | 0# (summer), 10# (winter) light diesel oil |
| Lube | LECD grade 15W40 |
| Excitation mode | Self-excitation and constant voltage(AVR) |
| Cooling system | Forced air-cooled |
