TECHNICAL DATA
Performance data |
|
|---|---|
| Impact energy | 3.2 J |
| Impact rate at rated speed | 0 – 4,000 bpm |
| Rated speed | 0 – 900 rpm |
Additional data |
|
|---|---|
| Rated input power | 880 W |
| Weight | 3.1 kg |
| Tool dimensions (length) | 402 mm |
| Tool dimensions (height) | 216 mm |
| Tool holder | SDS plus |
Drilling range |
|
|---|---|
| Drilling dia. concrete, hammer drill bits | 4 – 28 mm |
| Opt. appl. range concrete, hammer drill bits | 8 – 16 mm |
| Drilling diameter in concrete with core cutters | 68 mm |
| Max. drilling diameter masonry, core cutters | 68 mm |
| Max. drilling diameter in metal | 13 mm |
| Max. drilling diameter in wood | 30 mm |
Total vibration values (Hammer drilling in concrete) |
|
|---|---|
| Vibration emission value ah | 1.5 m/s² |
| Uncertainty K | 11 m/s² |
Total vibration values (Chiselling) |
|
|---|---|
| Vibration emission value ah | 1.5 m/s² |
| Uncertainty K | 11 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 90 dB(A); Sound power level 101 dB(A). Uncertainty K= 3 dB.
